PN 10-16
DN 40÷1800
FIG. 5000-5000V-5000VM-5000VMD
BODY
FIG.5000 – EN GJS-400-15 EN 1563 (OPT. EN10025 STEEL S275)
FIG.5000V – EN GJS-450-10 DUCTILE IRON EN 1563
FIG.5000VM – S275 CARBON STEEL EN 10025-2
FIG.5000VMD – S275JR CARBON STEEL EN 10025-2
GASKET EPDM (OPT. NBR) EN 681-1
SCREWS
FIG.5000-5000V – GALVANIZED STEEL EN 898-1 (OPT. STAINLESS STEEL EN10088)
FIG.5000VM-5000VMD – STEEL COATED IN SHERAPLEX
COATED INSIDE-OUTSIDE
FIG.5000
(FBE) EPOXY 250 MICRONS
FIG.5000V-5000VM-5000VMD
BLACK RILSAN NYLON 11 250 MICRONS (POTABLE WATER APPROVED)
D.M. NR.174 – HEALTH DEPARTMENT (I)
WATER
EN 12266-1 (ISO 5208) PRESSURE TESTS
